What we do

Pipe relining is a modern, trenchless repair solution designed to restore damaged sewer and stormwater pipes without the need for extensive excavation. At Help Plumbing, we specialise in pipe reline repairs across Sydney, providing long-lasting solutions for cracked, broken, or root-intruded pipework with minimal disruption to your property.

Using advanced CCTV drain cameras and electronic locators, we first inspect and assess the internal condition of your pipework to accurately identify defects such as fractures, joint failures, corrosion, or tree root intrusion. Once the affected section is confirmed, a resin-saturated liner is installed within the existing pipe and cured in place, creating a new, structurally sound pipe inside the old one.

This no-dig method eliminates the need to break concrete, dig trenches, or disturb landscaping, making it ideal for pipes located under homes, driveways, patios, or hard-to-access areas. Pipe relining also seals joints and prevents future root ingress, significantly extending the life of your drainage system. We test drainage flow, confirm pipe alignment, and carry out post-installation CCTV inspections to ensure the repair has been completed correctly.

How it works

Our standard process for every pipe relining job.

  1. 1

    Inspect

    CCTV camera survey to confirm relining is appropriate (some breaks are too severe and need traditional repair).

  2. 2

    Clean

    High-pressure jet blasting clears the pipe interior to bare wall — necessary for resin to bond properly.

  3. 3

    Install liner

    Resin-saturated felt liner inverted into the pipe through an access point. Inflated to press against the pipe wall.

  4. 4

    Cure & verify

    Resin cures in place to form a structural new pipe inside the old one. CCTV confirms the result.

Common pipe relining scenarios we handle

Real-world situations we see across Sydney every week — chances are one of these matches what's happening at your place.

  • Tree-rooted sewer line under a landscaped garden. Don't want to dig up the rose beds? Relining inserts a new pipe inside the old one — no excavation, no replanting.
  • Cracked clay pipe under a driveway. Breaking up the concrete to dig + relay the pipe is expensive and slow. Relining keeps the driveway intact.
  • Strata building stack with multiple cracks. Traditional repair means access through every apartment. Relining works from the access point only — minimal disruption to residents.
  • Recurring blockage with damaged pipe wall. If a CCTV inspection shows the pipe wall is the actual problem (not just root intrusion you can keep clearing), relining rehabilitates the pipe permanently.

Common issues we fix

  • Tree root intrusion through joints and cracks
  • Cracked or fractured pipe sections (with hairline-to-moderate damage)
  • Pipe corrosion in old earthenware or galvanised lines
  • Joint failures causing recurring blockages
  • Pipes under driveways, patios, or buildings (where excavation is expensive or impossible)
  • Heritage properties where digging would damage landscaping or paving

What's included in our pipe relining job

Every pipe relining job from Help Plumbing covers the full diagnostic-to-cleanup arc — not just the headline task.

  • Initial CCTV inspection to scope length + condition
  • High-pressure jet preparation of the existing pipe wall
  • Inversion of the resin-impregnated liner into position
  • In-situ cure (warm-cure or UV-cure depending on the material)
  • Final CCTV verification of the cured liner end-to-end
  • Manufacturer warranty paperwork — typically 25-50 years on the liner

Transparent pricing — no surprises

Every pipe relining job is quoted upfront in writing — diagnostic first, then a fixed price agreed before any work starts. No call-out surprises, no halfway-through "variations". If the scope changes (hidden damage discovered during the job, for instance), we pause, explain the variation, and quote it before continuing. You decide whether to proceed.

We don't quote pipe relining jobs sight-unseen over the phone. Diagnostic first, written quote second, work third — in that order. It's slower but it means the price you agree is the price you pay.

Why choose Help Plumbing for pipe relining

Help Plumbing has been delivering pipe relining across Sydney for years — NSW Plumbing Licence 489072C, $10M public liability insurance, and a 5.0★ rating across 51 Google reviews. Every job is carried out by a qualified, licensed plumber (not an unlicensed sub) with the right diagnostic equipment and the experience to use it correctly. We service 97 Sydney suburbs from our Earlwood workshop across the Inner West, Eastern Suburbs, Hills District, Parramatta, Western Sydney, Ryde, and Blue Mountains — same-day response is standard, after-hours and emergency callouts on the same number.

Pipe Relining — FAQs

  • Yes — modern epoxy resins are rated for 50+ year service lives. The new liner is structurally independent of the host pipe.

  • Often yes, especially under driveways, concrete, or tight access areas where excavation costs are high.

  • Slightly — usually 5–10 mm. Doesn't affect flow capacity in residential drains.

  • Most residential reline jobs are completed in 1 day. Curing takes 1–4 hours depending on the resin used.

  • Only briefly — usually under 4 hours. We schedule around your usage where possible.
